Implementing PS1 Rendering Characteristics with Godot psxlike
godot-psxlike is an MIT-licensed add-on for Godot 4+ that recreates PS1-style vertex snapping, affine texture mapping, dithering, lighting, and fog. Its shader-based workflow requires careful mesh sub
If you want to create a screen with the distinctive look of the PS1 in a Godot 4 project rather than relying on a simple low-resolution filter, godot-psxlike addresses several rendering constraints together. The add-on combines vertex snapping, affine texture mapping, per-model dithering, and fog and lighting processing to transform the smooth output of modern GPUs into something closer to the PS1’s rendering style.
Why Screen Shaking Alone Is Not Enough
Vertex snapping creates stepped jitter when vertices are moved to match the pixel grid of screen coordinates. Adding affine texture mapping makes surface textures appear warped depending on the camera angle. Applying both effects together reveals the characteristic movement of period 3D graphics, which is difficult to create with low resolution and post-processing alone.
Depth and Lighting Are Also Part of the Style
The add-on provides a depth buffer that uses a single planar depth value for each triangle, along with its own lighting system. Compared with modern per-pixel depth processing, this can produce rougher and less predictable results when objects overlap. Large surfaces can obscure nearby geometry or make texture distortion especially pronounced, so designing important areas with smaller triangles is essential.
Implementation Flow and Options
Copy the repository’s addons/psxlike folder into the project’s addons directory, activate the plugin, and reload the project. Then apply the psx_opaque material to opaque objects and psx_transparent to transparent objects, and place lights that interact with the renderer in the psx_light group. Because dithering can be adjusted per model rather than applied as a full-screen post-process, it is useful in scenes where the readability of the HUD or specific objects must be preserved.
The Scope of Fidelity
This approach recreates the PS1’s expressive limitations through shaders, but it does not reproduce every behavior of the original hardware exactly. In particular, the tessellation density of large meshes directly affects the impression of depth and texture distortion. Rather than applying the retro effect uniformly across the entire project, it is more stable to adjust mesh construction and fog intensity together according to camera distance and object size.
